Detailed Product Description

• Heater consists of a series of evacuated solar tube collectors and a water storage tank

• Can be refilled manually or by low pressure source

• Aerospace technology produces higher water temperatures than other solar systems

• High-capacity heater can provide household hot water needs for most of the year, depending on location

• It is easy to use and requires very low maintenance

• Mounts on rooftop or elevated area to let gravity do the work

• Can integrate with existing plumbing or operate as a stand-alone system

• Easy installation in 4–5 hours with only a wrench

• Includes stand, mounting hardware and instructions

• A dignifying impression, upgraded style.

• Inner tank: SUS3042B Food Grade Stainless Steel, superior water quality, drinkable.

• Bracket: Adoption of aluminum alloy or profiled bar, elegant and fashionable.

• Vacuum tube: Super heat pipe applied to heat collector no bursting or water leakage.

• Integral collector storage systems. do not use pumps or other electrical components, thereby providing a simple and reliable system.

Features:

1. Stable and reliable performance and well wind resistance

2. Vacuum heat-collecting tubes at high temperature

3. Dual-purpose brackets for both flat and inclined roof

4. Meeting the demand of well-to-do families

5. Thickness of bracket: 1.5mm

6. Heat-pipe vacuum tube: 58 mm x 1.8m

7. Inner tank: SUS304-2B food grade stainless steel

8. Outer tank: steel , long time durability

9. Insulating layer thickness: 55 - 60mm

10. Inner tank thickness of: 0.4 - 0.5mm

11. Tank diameter: 460mm

12. Heat preservation: 72hrs

13. Hail resistance: 25mm
